Siddhika Enterprises is the manufacturers and distributors of epoxy curing oven that helps all thermal process applications across major industries. We are always prepared to design and manufacture a custom Epoxy oven as per the client specifications. We have a team of innovative engineers that cater to your specific heating and drying needs with our patented industrial oven.
Our custom epoxy curing oven symbolizes our superior workmanship across a big curing ovens industry. The epoxy curing oven that we have come up with is designed to ensure maximum productivity while curing epoxy across multi-fiber and single connectors. Manufacturing and loading of 48 individual fiber connectors or 24 MT connectors for each cycle gain momentum with a modular carrier tray.
Among all industry players, we maintain a uniform thermal pattern within the industry alongside several interchangeable carrier trays that support all types of connectors.
Going through the process of curing is of great importance for an industrial product that needs to undergo proper heating and drying. It’s only then that our epoxy curing oven can be a crucial element of commercial and industrial coating and bonding. There is a chemical reaction behind turning epoxy to be used practically.
The reaction needs considerable time and needs specific conditions for delivering the desired outcome. There are many factors that contribute to epoxy curing. It includes preparing the material that holds the epoxy, consistent epoxy application, dryness, and proper blending of the epoxy and high temperatures.
| Size of the working chamber | As per client requirement. |
| Material of construction | Mild Steel, Stainless Steel 304 / 316 or any. |
| Temperature Range | Ambient to 1500C / 2500C / 4000C / 5000C. |
| Air circulation | Vertical, Horizontal or Combination. High Volume and high Velocity Airflow provides twice the air changes compare to ordinary Industrial Ovens. |
| Timer | Digital Pre-Settable with range up to 0 to 999 Minutes / Seconds |
| Paint | Enamel Paint / Epoxy Coating / Powder Coated. |
| Power supply | 230 Volts Single Phase 50Hz / 60Hz 415 Volts 3 Phase 50Hz / 60Hz |
| Heating Elements | Low wattage Incoloy sheathed heating elements / SS Tubular |
| Insulation | Ceramic Wool / Mineral Wool |
| Door Gasket | Fibre Glass Rope (High Temp) / Silicon Gasket. |
| Heavy Duty Shelves / Trays | Made out of angles with wire knitted mesh or perforated sheet suitable for oven internal size will be provided along with the oven. |
| Exhaust Manual or Automatic | Automatic forced exhaust system with fresh air inlet. Manually adjustable damper with fresh air inlet. |
| Heating Media | Electric / Gas / Diesel / Steam / Thermic OIL etc. |
